• Wireless charging.
• 2.5 hours double fast charging.
• BMS protection.
• PV charge with MPPT tracker.
• Full compatibility with iPhone,iPad,Mac, Android.
• LiPePO4 battery with 2000-2500+ cycles life.
Local gluing not only saves dust-proof cotton and exhaust fans in the design of charging piles but also can reliably and continuously run for a long time without maintenance in various harsh environments such as dust, salt spray, and condensation.
ModelP1-TR100030
Capacity30KW
Input voltage260Vac~485Vac, Three-phase without neutral
Maximum Input Current58A
Grid Frequency45Hz~65Hz
Power Factor≥0.98(over half load)
Max. efficiency＞95%
THD＜5%(over half load)
Regulated Output Voltage Adjust Range
200Vdc-1000Vdc
Constant Power Voltage 300Vdc-1000Vdc
Output Current0-100A
Output Current Limit1-100A Continuous adjustable
Output Voltage Ripple facto(25℃)＜1%
Current Unbalance＜±5%
Voltage stablized Accuracy＜±0.5%
LiPePO4 | Wide Range
LiPePO4 | Wide Range
